TYSHC Stringing Pulley Aluminum Wheel Cross Arm Mounted Stringing Block
  • name
  • name

TYSHC Stringing Pulley Aluminum Wheel Cross Arm Mounted Stringing Block

MOQ: 50pieces
Price: Negotiable
Standard Packaging: Container
Delivery Period: 15-35days
Payment Method: L/C, T/T
Supply Capacity: 3000pieces/month.
Detail Information
Product Description
Detail Information
Place of Origin
China
Brand Name
HANYU
Certification
ISO9001
Model Number
SHC-0.5
Type:
TYSHC Cross Arm Mounted Stringing Block
Conductor:
25~120mm2
Rated Load:
5kN
Outside Diameter Of Wheel:
80mm
Weight:
1.6kg
Wheel Material:
Aluminum
Highlight:

TYSHC Stringing Pulley

,

Cross Arm Mounted Stringing Block

Product Description

Stringing Pulley TYSHC Aluminum Wheel Cross Arm Mounted Stringing Block



TYSHC Cross arm Mounted Stringing Block
Model Conductor (mm2) Rated load (kN) Outside diameter of wheel (mm) Weight (kg) Wheel material
SHC-0.5 25~120 5 80 1.6 Aluminum
SHC-2 35~240 20 120 2.9
SHCN-0.5 25~120 5 80 1.2 Nylon
SHCN-2 35~240 20 120 2.4
SHCN-2.5 35~240 25 140 3.2



TYSHC Stringing Pulley Aluminum Wheel Cross Arm Mounted Stringing Block 0





1. What is the advantage of HANYU compared to other suppliers?

Since the manufacturing team all possesses years of experience, HANYU can provide competitive price and superior service. We have professional sales team, production team, researching team.

2. What is the price policy of your company?

In our company, the price is different according to the quantity of your order, the more the cheaper. For more detailed information, you can contact our customer service representatives.

3. What are the features of the services your company offered?

Based on the wide product range, we offer the best One-Stop sourcing service and all-around after-sales service . We will definitely save you a lot of time and money. It will improve your efficiency significantly and be more economical.

4. What is the payment of your company?

HANYU accepts the payment of T/T and L/C, everything can be further discussed.
